• Input Sensitivities (for rated output of 1.5V Moving Coil (high gain) 200μV
• Moving Magnet (low gain) 2.0mV
• All others (Aux. etc.) 110mV

Input Overload

• Moving Coil (high gain) 120mV
• Moving Magnet (low gain) 1.2V
• All others (Aux. etc.) 50V maximum input level
• Rated Output 1.4V
• Maximum Output 27V
• Main Output Source Impedance 470Ω
• Tape Record Output (source impedance 2kΩ)
• For rated input sensitivity 110mV
• Minimum recommended load 10kΩ

Frequency Response

• All others (Aux. etc.) to main out 20Hz to 50kHz ±0.25dB

Total Harmonic Distortion

• Moving Coil and Moving Magnet (rated input sensitivity) 0.005%\
• Moving Magnet (0.9V input @ 1kHz) 0.010%
• Moving Coil (0.09V input @ 1kHz) 0.010%
• All others (Aux. etc. at rated input sensitivity) < 0.0009%
• All others (Aux. etc. at 1kHz into 10kΩ or higher) < 0.0009%
• 100kHz at rated output into 10kΩ < 0.008%

Intermodulation Distortion

• All inputs up to rated input and output < 0.005%

Noise (inputs loaded)

• Moving Coil (high gain) -64dB lin, 20Hz-20kHz referenced to rated input (72dBA)
• Moving Magnet (low gain) -78dB lin, 20Hz-20kHz referenced to rated input (86dBA)
• All others (Aux. etc.) -104dB lin (108dBA)

R.I.A.A. Accuracy

• Reference I.E.C. Publication No. 98 amendment No.-4 1976 ±0.25dB

Channel Separation

• All inputs 20Hz-20kHz 70dB

Phase Accuracy

• Aux. etc. ±1° 20Hz-20kHz
• Slewing 70V/μs

Dimensions

• Width 482mm (19.0")
• Height 50mm (1.8")
• Depth 342mm (12.5"
