Description: Single-box D/A provessor.

Conversion: Bitstream, PDM—256x resampled.

Data input sampling range: 40kHz–50kHz.

Digital filter: 4x.

Analog post filter: 3rd-order at 60kHz.

Noise shaping: second-order.

Inputs: coaxial on an RCA jack, optical on a Toslink jack.

Outputs: RCA jacks, 2.75V output level at full scale. Three front-panel indicators: analog/digital power, incoming data lock.

Frequency response: 20Hz–20kHz ±0.2dB.

Resolution: 16 bits. THD+noise: –90dB.

S/N ratio: greater than 93dB. Channel separation: 80dB (no frequency specified). Linearity: ±1dB at –90dB, ±2dB at –100dB.

De-emphasis error: ±0.25dB.

Dimensions: 8.5" W by 1.75" H (front panel), 7.4" W by 1.75" H by 5.75" D (chassis including jacks).

Shipping weight: 5 lbs.
